Model 5700 Installation and Operation Manual 151295
7-19
11. Repeat Steps 1 through 15 for all circuits.
Table 7-5 Menu choices for Internal/External Power Modules
Choices Type Selections
Function
Selections for
each Type
Comments
Enter Point or
Circuit
Select Type
UNUSED
NOTIF OUT
CTRL CKT
AUX PWR CONSTANT Constant auxiliary power.
RESETTABLE Resettable auxiliary power.
DOOR Door holder auxiliary power.
SOUNDER SYNC Sounder Sync auxiliary power.
B SWITCH MAN PULL Refer to comments column of
Table 7-5 for description of these
options
Latch or Non-latching feature only
appears for waterflow, supervisory,
tamper, zone aux1, zone aux2, system
aux1, and system aux2
WATERFLOW
SUPERVSY
TAMPER
FIREDRILL
SILENCE
RESET
PAS_ACK
ZN_AUX1
ZN_AUX2
SYS_AUX1
SYS_AUX2
MAN REL
ILOCK
STATUS POINT Non-latching - Used to activate an
ancillary Output Group that does not
active alarm, sound PZT, display status
or report events. Reset has no affect on
this point
A SWITCH Same as B SWITCH
B DETECTOR 2-WIRE SMK Used for Class B, 2-wire detectors
4-WIRE SMK Used for Class B, 4-wire detectors
4-WIRE CO SMK Used for Class B, 4-wire CO detectors
A DETECTOR 2-WIRE SMK Used for Class A, 2-wire detectors
4-WIRE SMK Used for Class A, 4-wire detectors
4-WIRE CO SMK Used for Class A, 4-wire CO detectors
Select Group Group or Zone selection will appear
depending on the type selected
Edit Name See Section 7.5.4.
