Model 5700 Installation and Operation Manual
151295
7-31
7.6.7
Edit Banner
The banner is the message that displays on the panel LCD when the system is normal, that is, when no alarms or
troubles exist and no one is currently using system menus. You can create a customized message, which can be
up to 40 characters, two lines of 20 characters each.
If you do not create a customized message, the system will use the internal banner. You cannot change the
internal banner.
To customize the banner display message:
1.
Enter the installer code.
2.
Select 7 for Program Menu.
3.
Select 5 for System Options.
4.
Select 8 for Edit Banner.
A screen similar to the one shown in Figure 7-23 will display.
Figure 7-20 Internal Banner Message
5.
Press the
or
arrow to select “Custom”, then press
ENTER
.
A screen similar to the one shown in Figure 7-24 will display.
Figure 7-21 Custom Banner Edit Screen
6.
Select each character of a word by pressing the
or
arrow, then press
to move to the next character.
7.
When word or sentence is complete press
ENTER
to move to line two of the custom banner. Repeat step 6
and 7.
7.6.8
SLC Family
The 5700 supports SD protocol SLC devices or Intelligent SK series SLC devices. You must configure the 5700
to accept the protocol of the devices you are installing. You cannot mix SLC devices of different protocols.
1.
Enter the installer code.
2.
Select 7 for Program Menu.
3.
Press 0 to enter module menu.
4.
Press
to select the desired SLC device type.
5.
Press
ENTER
to accept the displayed SLC device type.
