Before You Begin Installing 151295
3-6
3.6.2 Current Draw Worksheet for SK SLC Devices
Use Table 3-2 to determine current requirements during alarm/battery standby operation when SK SLC devices
are installed. (Copy the page if additional space is required.) You can install up to 50 SK detectors and 50 SK
modules.
Table 3-2: Current Calculation Worksheet for SK Devices
Device
# of
Devices
Current per Device
Standby
Current
Alarm
Current
For each device use this formula: This column X This column = Current per number of devices.
Fire Panel (Current draw from
battery)
1
Standby: 200 mA 200 mA
Alarm: 365 mA 365 mA
Addressable SLC Detectors
SK-Photo
(50 max.) 1
Standby/Alarm: .30 mA 6
mA mA
SK-Photo-T mA mA
SK-Ion mA mA
SK-Heat mA mA
SK-Heat-HT mA mA
SK-Acclimate mA mA
SK-Heat-ROR mA mA
SK-DUCT
5 mA mA
SK-Beam (without integral test)
SLC Standby/Alarm: 2 mA mA mA
Aux. Pwr
Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-Beam-T
4
(with integral test)
(50 max.) 1
SLC Standby/Alarm: 2 mA
Aux. Pwr
Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-FIRE-CO SLC
Standby: .30 mA mA
Alarm: 7.2 mA mA
Addressable SLC Modules
SK-Monitor
(50 max.) 1
Standby/Alarm .375 mA
mA mA
SK-Minimon mA mA
SK-Pull-SA/SK-Pull-DA
SK-Monitor-2 Standby/Alarm: .75 mA mA mA
SK-Mon-10 Standby/Alarm: 3.5 mA mA mA
SK-Control
SLC
Standby: .375 mA
Alarm: .375 mA
mA
mA
Aux Pwr
Standby: 1.7 mA mA
Alarm: 7 mA mA
SK-Control-6
SLC
Standby: 2.25 mA
Alarm: 2.25 mA
mA
mA
Aux Pwr
Standby: 8 mA mA
Alarm: 20 mA mA
SK-Relay Standby/Alarm: .255 mA mA mA
SK-Relay-6 Standby/Alarm: 1.45 mA mA mA
SK-RelayMon-2
Standby: 1.3 mA mA
Alarm: 24 mA mA
