2 facp connection, 2 facp connection -18 – SilentKnight 5700 User Manual
Page 47
Control Panel Installation
151295
4-18
4.7.2
FACP Connection
The 5880 connects to the panel via the SBUS. Make connections as shown in Figure 4-20. After the 5880 is
connected to the panel, it must be added to the system. This programming step is described in Section 4.9.
Figure 4-20 5880 Connection to Main Control Panel Assembly
Supervised
Power Limited
