Page 32
Model 5700 Installation and Operation Manual
151295
4-3
4.2
AC Connection
At installation, connect the AC terminals to the power source as shown in Figure 4-2. It may be necessary for a
professional electrician to make this connection.
The AC terminals are rated at 120 VAC, 60 Hz, 1.5A.
Figure 4-2 120VAC Power Connection
To AC
Ground
Supervised
