SilentKnight 5700 User Manual
Page 61
Control Panel Installation
151295
4-32
Wire the SD500-ARM as shown in Figure 4-37.
Figure 4-37 Polarity Reversal Connection Using the SD500-ARM Module
UL Listed
EOL
Intended for Connection to a
Polarity Reversal Circuit of A
Remote Station Receiving Unit
Having Compatible Rating.
Supervised
Power Limited
To Remote
Receiving Station
UL Listed
EOL
Note: UL Listed EOL
must be permanently mounted
