SilentKnight 5700 - Manual (Page 102)

Programming 151295
7-4
7.3.1.1 Edit Zone Name
6. To edit the zone name, press 1.
A screen similar to the one shown in Figure 7-2 displays.
Figure 7-2 Selecting Character for Zone Name
7. Select the characters for the zone name by pressing the or arrow until the desired character is shown
then press . Or Enter the Numerical Designator for the character you want, then press . See Appendix
B Table B-1 of this manual for a list of available characters and their numeric designators.
8. Repeat step 8 until the name is complete.
9. Press ENTER when the name is complete.
7.3.1.2 Edit Zone Properties
Zone properties consist of, alarm delay characteristics, and heat detector sensitivity.
1. Do steps 1 through 5 of Section 7.3.1.
2. Press 2 to edit the properties of the selected zone.
Figure 7-3 Edit Zone Properties
Detection type also selected from
this screen (see Table 7-1).
