SilentKnight 5700 User Manual
Page 116
Programming
151295
7-18
7.5.2
Point Programming For Internal or External Power Module
To program for an internal or external power module points, follow these steps:
1.
Enter the installer code.
2.
Select 7 for Program Menu.
3.
Press 4 to enter point menu.
4.
Press the
or
arrows to select the desired module. Press
ENTER
. Refer to Section 6.5 for available
choices.
5.
Enter the number of the circuit or point you wish to edit. Refer to Table 7-6 for available selections.
6.
Press
ENTER
.
7.
Select the type by pressing the
or
arrows, then press
ENTER
.
8.
Select the function by pressing the
or
arrows, then press
ENTER
.
9.
Select the group by pressing the
or
arrows, then press
ENTER
.
10. Edit point name. Press
to skip point name edit. See Section 7.5.4.
SLC Loop
(cont.)
RELAY
OUTPUT PT
Select Group
Output Point, a general use relay type. Use for
applications requiring a relay, such as elevator
recall.
AUX RESET
Use for auxiliary power, resettable applications.
See Section 4.11.2.3 to learn how this option
operates.
AUX DOOR
Use for auxiliary power, door holder applications.
For example, if you were using an auxiliary power
supply for door holders, you would use this option.
See Section 4.11.2.1 for a description of how this
option operates.
Table 7-4: Point Programming
Module Type
Type
Selection
Function
Latching
Option
Comments
