Programming
151295
7-20
7.5.3
Point Programming For 5880 and 5865 Modules
To program for a 5880 or 5865 module points, follow these steps:
1.
Enter the installer code.
2.
Select 7 for Program Menu.
3.
Press 4 to enter point menu.
4.
Press the
or
arrows to select the desired module. Refer to Section 6.5 for available choices.
5.
Press
ENTER
.
Figure 7-11 Programming Points Screen for 5880 and 5865 Modules
6.
Enter the point number.
7.
Press
ENTER
.
8.
Press the
or
arrows to select the type (Notification or unused).
9.
Press
ENTER
.
10. Press the
or
arrows to select the desired Group.
11. Press
ENTER
.
12. Edit module name. See Section 7.5.4.
Or
Press
to skip module name edit.
13. Repeat Steps 1 through 13 for all points.
7.5.4
Assigning a Name to a Points
You can assign a name to a point to make it easier to recognize on a display.
If you wish to edit the name of a point, follow these instructions:
1.
Do steps 1 through 4 of Section 7.5.3.
2.
Using the
or
arrow, select the module of the point you want to edit, press
ENTER
.
3.
Enter the point number.
4.
Press
until the module name is blinking.
5.
Press
ENTER when finished
.
