CV-H5N-M-WW-NO2-E 2-29
3. Log file creation
1
Select [Create a data log file] under the selected connection
from the [Connection] menu, then select the [General] tab in
the [Create a data log file] dialog to set the folder to save
data to.
This example sets the save-to location to “F:\Keyence\log”.
Refer to "Creating a Log File" (page 4-11).
Example: “Create a data log file” dialog “General” settings
2
Select the [Options] tab, then set the acquisition
conditions and the save file name.
Refer to "Creating a Log File" (page 4-11).
Example: “Log file settings” dialog “Option” settings
