CV-H5N-M-WW-NO2-E 2-24
2
6
Click the [Execute] button.
A confirmation message appears.
Note
All the target data to read is deleted on execution.
Before executing, make sure that the CV-5001 Series controller is
set to [Run] mode.
7
Click the [Yes] button.
A message will appear indicating that the data has been
successfully loaded.
8
Click the [OK] button to return to the main window.
Reference
Using load target and global data
When global data is loaded from a CV-5001 Series controller, the
program no. currently being used on the simulator will be changed
to the number on the controller.
To set the physical controller to the same program number as the
simulator, first load only the global data. Then close the [Transfer
Programs] menu and load the program data and saved images.
■ Editing a program file that has been read
1
Using a keyboard, you can perform the same operations
as the CV-5001 Series physical controller using a
console.
The relationship between the buttons on the console and the
keyboard is shown in Table 1.
Refer to CV-5001 Series controller “User's Manual" (supplied
with the CV-5001 Series products) for how to operate the CV-
5001 Series product.
Note
Some functions cannot be operated by the simulator.
Refer to "Simulator" (page 4-29) for details.
2
Save the program that has been edited in step 1.
7
8
Table 1
Relationship between the menus on
the console and the keyboard
Remote control console Keyboard
ENTER Enter
Up n
Down p
Right o
Left m
ESCAPE E/ESC
FNC F
TRG T
SCREEN S
VIEW V
MENU M
PROG/RUN P/R
