CV-H5N-M-WW-NO4-E

4-28

Enabling Data Collection

Select [Start collection] from the [Data Collection] menu
or click the [Start collection] icon in the toolbar.

Data collection begins.

Reference

When collection starts, the [End collection] icon will appear in the

toolbar (red) and the [Collection status] icon on the status bar will

appear green.

Note

Data collection will not begin if the CV-5001 Series controller is not

connected.

Ending Data Collection

Select [End collection] from the [Data Collection] menu
or click the [End collection] icon in the toolbar.

Data collection stops.

Reference

When collection stops, the [Start collection] icon will appear in the

toolbar (green) and the [Collections status] icon on the status bar

will appear red.

Note

Data collection cannot be stopped if the CV-5001 Series controller

is not connected.
