2 | The NGC Instrument
86 | NGC Chromatography Systems and ChromLab Software
Product Configurations
The NGC chromatography system is available in four standard configurations. This
section lists the modules available for each configuration. You can add or remove
modules to an existing configuration to customize the system. The configuration at
your site might differ slightly from any of the standard configurations.
Note: All NGC systems are available with
either the 10 ml/min or the
100 ml/min system pumps.
Table 9. NGC chromatography system configurations
Module NGC Quest NGC Scout NGC Discover NGC Discover Pro
Sample injection valve
   
Single-wavelength UV and
conductivity monitor
(Available on the NGC
Quest and NGC
Scout
systems only)
 
Multi-wavelength UV/Vis
and conductivity monitor
(Available on all NGC
systems)
 

*

*
System pumps A and B    
Mixer    
pH valve   
Buffer blending valve
  
Column switching valve 1  
Sample pump  
Buffer inlet valves A and B  
Third expansion tier  
