The NGC Instrument Illustrated
Instrument Guide | 23
L EGEND
1 Touch screen monitor 2 Sample pump
3 Sample inlet valve 4 Buffer tray
5 Empty bay, covered 6 LED display
7 Multi-wavelength UV/Vis detector 8 Conductivity monitor
9 Outlet valve 10 pH detector
11 Column and peripheral mount 12 Columns
13 Column grip 14 Column-switching valve
15 Buffer inlet B 16 Peripheral ports
17 USB ports and soft power switch 18 System pump B
19 Drip tray 20 Mixer
21 Buffer blending valve 22 System pump A
23 Buffer inlet A 24 Inject valve
25 Touch screen mounting arm
