Plumbing the NGC Discover Pro System
Table
23 lists the tasks for plumbing the NGC Discover Pro system. The tasks are
explained in detail in the sections that follow.
Note:
Ensure that you complete the plumbing tasks in the sections
Plumbing the NGC Discover System on
before continuing.
The figure on page
284 shows the Point-to-Plumb connections for the
NGC
Discover Pro system.
Table 23.
Plumbing tasks for the NGC Discovery Pro systems
Tasks
1.
Tube #6 between the outlet port on the sample inlet valve and the
inlet port on the sample pump
Note:
Remove the inlet tubing from the sample pump inlet
manifold if it is installed.
2.
Connect one of the following:
Tube #4 from the Common inlet port on the BioFrac fraction
collector diverter valve to port 1 on the outlet valve
Waste tubing to port 1 on the outlet valve
3.
Inlet tubing to the remaining ports on the sample inlet valve
See the section
Plumbing Sample Inlet Valves on page
.
4.
Outlet tubing to the remaining ports on the outlet valve
See the section
