1 | Introduction
14 | NGC Chromatography Systems and ChromLab Software
 Extend the preconfigured systems with additional valves for buffers,
samples, and columns
 Organize the location of the modules to optimize separation performance
based on method scale and complexity, and to minimize the system swept
volume
 Minimize errors when connecting tubing using the Point-to-Plumb™
feature in ChromLab software
Site Requirements
Power Considerations
Note: The power supply to the NGC system must be stable and within
specifications at all times to ensure optimal operation. The power cable
connected to the power inlet port must be rated for 7 amps or more.
Table 1. Power requirements for the NGC system and ChromLab
Parameter Requirement
Mains input voltage AC 100—240 V; 50—60 Hz
NGC maximum power usage <750 watts
Number of power sockets Minimum of three power sockets:
 One socket for the NGC instrument
 One socket for the computer running
ChromLab
 One socket for the BioFrac™ fraction
collector
 A socket for any supported peripheral
instrument that you attach (for example,
the C-96 autosampler)
Tip: The touch screen does not
require a separate power supply.
Type of power sockets IEC type connections, grounded sockets
