Fault Location Mode

65

Figure 31 Setting the Graph Display

Step

Action

1

Press the Config key

2

Press the Scale softkey

3

Press the left or right scroll key to select
Disp

4

Press the up scroll key to open the selec-
tion list

5

Press the up or down scroll key to select a

display type (envelope, maximum, minimum)

6

Press the Enter key to accept the selection
and return to the configuration screen
