130
Specifications
Antenna Testing
Test Port
Connectors
Impedance
Female N normally supplied
50 Ohms
Directivity, After Calibration ConnectorFrequencyDirectivity
N 25 – 2500 MHz – 42 dB
N 2.5 – 6.0 GHz – 38 dB
7/1625 – 2500 MHz – 40 dB
7/162.5 – 6.0 GHz – 35 dB
Source VSWR
All models < 300 MHz 2.00:1
300 - 6000 MHz 1.25:1
Measurement Speed < 4 seconds / sweep, test port open, Y-axis
set to full scale
238 data points
475 data points
949 data points
< 2 seconds / sweep
< 3.5 seconds / sweep
< 6 seconds / sweep
Immunity to Interfering
Signals
≤ 13 dB interferer at desired measurement
frequency.
Maximum Input Signal
(Damage Level)
≤ 22 dBm
Output Power 0 dBm, nominal
Match Measurement
Frequency Range
SA-2500EX
SA-1700EX &
SA-1700EXP
SA-6000EX
780 – 2500 MHz
25 – 1700 MHz
25 – 6000 MHz
Frequency Resolution
SA-2500EX
All other models
25 – 800 MHz
800 – 2500 MHz
2500 – 6000 MHz
50 kHz
25 kHz
50 kHz
100 kHz
Frequency Accuracy ± 100 kHz (25 MHz to 1 GHz)
± 50 ppm (1 GHz to 6 GHz)
Number of Data Points 238 (default), 475, 949
Measurement Range and Resolution
Return Loss
VSWR
RangeResolution
0.0 to –60.0 dB0.1 dB
1.00 to 99.990.01
