48
Note: Changing the frequency settings will automatically
turn calibration off. Always set the frequency before calibrating
the unit.
Note: If you enter a frequency that is outside of the range
of the Site Analyzer, the Site Analyzer will override your entry
and set the minimum or maximum frequency of the model.
Select Fault Location Mode
1. Apply power to the Site Analyzer. Press and hold the ON/OFF key
for at least 1/2 second then wait for the unit to go through its
power-on initialization.
2. To select the Fault Location mode, follow the numbered steps in
Figure 19 on page 48.
Figure 19 Select Fault Location Mode
Step Action
1 Press the Mode key
2 Press the Fault Location softkey
