Measure Match Mode

41

Figure 16 Using Markers with Recalled Traces

Step

Action

1

Press the Marker key

2

Select single mode or dual mode

3

Select a marker

4

Press the left or right scroll key to move the
marker

5

Press Esc to return to the test screen
