Site analyzer xt series
Site Analyzer XT Series
SA-3600XT, SA-6000XT
}
One unit covers the entire 25-6000 MHz range!
}
Easy to operate and field ready for first-time, occasional and experienced users.
}
Other applications include 3G, Broadcast, Government, Tactical Military, Microwave, Paging, Public
Safety, Trunking, WLAN andWLL, and TETRA.
}
Color display is clearly visible in direct sunlight.
}
With a single download you can view data as Distance to Fault or Measurement Match-no need to
store two traces.
}
FDR (Frequency Domain Reflectometry) measurement method results in a highly reliable assessment of
the health of critical components in your system; ultimately providing a “heads-up” before a failure
occurs.
}
Fault location or DTF mode indicates VSWR or Return Loss levels at each point along the cable and
antenna system length.
}
Cable Loss function measures insertion loss of the cable system over a given frequency range.
}
USB communication ports for connection to PC, field sensors and storage devices.
APPLICATIONS
Suitable for use in Worldwide Cellular and PCS/DCS systems; supporting measurement of
CDMA, GSM, TDMA and AMPS modulation schemes.
Other applications include 3G, Broadcast, Government, Tactical Military, Microwave, Paging,
Public Safety, Trunking, WLAN and WLL, and TETRA.
