Introduction
9
Power Up
For the first power-up and after a failure, reset the unit (refer to
Return to Defaults, page 119).
Self Test
The unit performs an automatic self test at power up. If the self test
fails, refer to Troubleshooting, page 126 for possible causes and correc-
tive action. If the problem persists, return the unit for service.
The self test screen also displays the software revision information as
shown below.
System Information
Before you use the Site Analyzer, record the following system informa-
tion:
•
Frequency Span — ex: 824-894 MHz (cellular band)
•
Cable Type — ex: LDF 7 - 50A
•
Approximate Cable Length — ex: 300 feet
•
Transmitter Power — ex: 50 W
WARNING
This equipment should not be connected to an
antenna or operated during a storm that has the
potential to produce lightning.
The possibility exists for electrical shock.
Model SA-6000EX, 25 - 6000 MHz
Feb 2005
SN: 00000000
22
Copyright © 1998 - 2005 by Bird Electronic Corporation
