Fault Location Distance - 238 Data Points
Fault Location Distance and Resolution - 238 Data Points
Vel Prop
0.66
0.88
Freq Span
Max Distance
Resolution
Max Distance
Resolution
(MHz)
ft
m
in
cm
ft
m
in
cm
25
999.9
937.9
155.8
395.7
999.9
999.9
207.7
527.6
50
999.9
468.9
77.9
197.9
999.9
625.2
103.9
263.8
75
999.9
312.6
51.9
131.9
999.9
416.8
69.2
175.9
100
769.2
234.5
38.9
98.9
999.9
312.6
51.9
131.9
200
384.6
117.2
19.5
49.5
512.8
156.3
26.0
66.0
300
256.4
78.2
13.0
33.0
341.9
104.2
17.3
44.0
400
192.3
58.6
9.7
24.7
256.4
78.2
13.0
33.0
500
153.8
46.9
7.8
19.8
205.1
62.5
10.4
26.4
600
128.2
39.1
6.5
16.5
170.9
52.1
8.7
22.0
700
109.9
33.5
5.6
14.1
146.5
44.7
7.4
18.8
800
96.2
29.3
4.9
12.4
128.2
39.1
6.5
16.5
900
85.5
26.1
4.3
11.0
114.0
34.7
5.8
14.7
1000
76.9
23.4
3.9
9.9
102.6
31.3
5.2
13.2
1500
51.3
15.6
2.6
6.6
68.4
20.8
3.5
8.8
2000
38.5
11.7
1.9
4.9
51.3
15.6
2.6
6.6
2500
30.8
9.4
1.6
4.0
41.0
12.5
2.1
5.3
3000
25.6
7.8
1.3
3.3
34.2
10.4
1.7
4.4
3500
22.0
6.7
1.1
2.8
29.3
8.9
1.5
3.8
4000
19.2
5.9
1.0
2.5
25.6
7.8
1.3
3.3
4500
17.1
5.2
0.9
2.2
22.8
6.9
1.2
2.9
5000
15.4
4.7
0.8
2.0
20.5
6.3
1.0
2.6
5500
14.0
4.3
0.7
1.8
18.6
5.7
0.9
2.4
5975
12.9
3.9
0.7
1.7
17.2
5.2
0.9
2.2
