Statistical Power Sensor
7022
Bird offers a new thruline sensor for measuring and maintaining your most complex wireless systems. The
Statistical Power Sensor is a rugged, easy to use field instrument that uses statistical sampling techniques.
In modern communications, signal average power, although important is no longer a sufficient control variable.
These communication signals often require more diagnostic measurements. In the statistical mode, the
power sensor measures the precentage of time the signal exsists at a specific peak-to-average ratio. In the
time domain mode, the sensor adds a variety of functions similar to an oscilloscope to our standard suite of
measurements.
The statistical power sensor can be used in all known communication formats and is able to accurately
measure a wide range of RF measurements for non-periodic signals such as EVDO, UMTS, LTE, and HDTV.
Like all Bird Sensors, its calibration is also traceable to NIST standards with no field calibration required.
APPLICATIONS
WPS MEASURES: Analog Cellular, Digital Cellular, 3G, 4G,
Tetra, APCO/P25 Phase 1 & 2, DMR, MOTOTRBO, Trunking,
CDMA, TDMA, WCDMA, GSM, Transportation, Tactical Military,
Radar, Avionics, Marine, LMR, Analog Broadcast, Digital
Broadcast, GSM, GPRS, EDGE, UMTS, HSDPA, Bluetooth, Fire,
GPS, NPSPAC, Paging, Public Safety, Telematics, Utilities,
WIMAX, WLAN, EVDO, UMTS, LTE, and HDTV.
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
TIME DOMAIN MODE
} Detailed breakdown of a single or multiple pulses.
} Includes a wide range of IEEE pulse parameters.
} Markers allows user to focus on particular portions of the
signal for analysis.
STATISTICAL MODE
} Analytical results of Signal of Interest using CCDF parameters.
} Isolate and identify specific breakpoints with the use of
markers.
AVERAGE POWER MODE
} Extremely accurate true average power measurements.
} True Average measurement of Forward and Reflected power.
} All related reflection calculations.
} Peak Power measurement.
} Burst Measurement of Pulse Power.
PowerSensor_Stasticatical 7022_2012 branding 10/20/2014 1:09 PM Page 1
