Measure Match Mode

37

Figure 13 Moving Markers

Step

Action

1

Press the Marker key to enter marker
setup

2

Press the Mark softkey to select a marker
(1-6)

3

Press the right or left arrow keys to move
the marker right or left, or enter a fre-
quency value on the keypad and press
Enter

4

Press the up arrow keys to move the
marker to the highest point on the trace

5

Press the down arrow key to move the
marker to the lowest point on the trace

6

Press Esc to return to the test screen
