Page 51

background image

Measure Match Mode

35

Figure 12 Activate Marker and Set Style

Step

Action

1

Press the Marker key to enter marker
setup

2

Press the Mark softkey to select a marker
(1-6)

3

Press the Active / Off softkey to turn ON
the selected marker (active) or turn OFF
the selected marker (off)

4

Press the Type softkey to select triangle
marker (4 in figure) or line marker (1 in
figure)

Repeat Step 2 through Step 4 to select and
activate up to six markers and set the
mark style

5

Press the Esc key to return to the test
screen
