Measure Power Mode
101
The antenna test port is used only for testing unpowered systems. For
power measurement, you must connect an external power sensor to
the “Remote Power Sensor” port (see Figure 56 on page 100).
For best results with element-based sensors such as the Bird 5010B,
connect the sensor and enter the forward element’s power rating before
taking any data (refer to Setting the Full Scale Power, page 103).
CAUTION
+22 dBm max. input
Do not apply RF power to Antenna Test Port.
Exceeding the maximum input will damage the Site
Analyzer.
CAUTION
When using a Bird 5011 or 5011-EF, do not exceed 2
W average or 125 W peak power for 5 µs. Doing so
will render the sensor inoperative.
