Fault Location Distance - 475 Data Points
Fault Location Distance and Resolution - 475 Data Points
Vel Prop
0.66
0.88
Freq Span
Max Distance
Resolution
Max Distance
Resolution
(MHz)
ft
m
in
cm
ft
m
in
cm
25
999.9
999.9
155.8
395.7
999.9
999.9
207.7
527.6
50
999.9
937.9
77.9
197.9
999.9
999.9
103.9
263.8
75
999.9
625.2
51.9
131.9
999.9
833.7
69.2
175.9
100
999.9
468.9
39.0
98.9
999.9
625.2
51.9
131.9
200
769.2
234.5
19.5
49.5
999.9
312.6
26.0
66.0
300
512.8
156.3
13.0
33.0
683.8
208.4
17.3
44.0
400
384.6
117.2
9.7
24.7
512.8
156.3
13.0
33.0
500
307.7
93.8
7.8
19.8
410.3
125.0
10.4
26.4
600
256.4
78.2
6.5
16.5
341.9
104.2
8.7
22.0
700
219.8
67.0
5.6
14.1
293.0
89.3
7.4
18.8
800
192.3
58.6
4.9
12.4
256.4
78.2
6.5
16.5
900
170.9
52.1
4.3
11.0
227.9
69.5
5.8
14.7
1000
153.8
46.9
3.9
9.9
205.1
62.5
5.2
13.2
1500
102.6
31.3
2.6
6.6
136.8
41.7
3.5
8.8
2000
76.9
23.4
1.9
4.9
102.6
31.3
2.6
6.6
2500
61.5
18.8
1.6
4.0
82.1
25.0
2.1
5.3
3000
51.3
15.6
1.3
3.3
68.4
20.8
1.7
4.4
3500
44.0
13.4
1.1
2.8
58.6
17.9
1.5
3.8
4000
38.5
11.7
1.0
2.5
51.3
15.6
1.3
3.3
4500
34.2
10.4
0.9
2.2
45.6
13.9
1.2
2.9
5000
30.8
9.4
0.8
2.0
41.0
12.5
1.0
2.6
5500
28.0
8.5
0.7
1.8
37.3
11.4
0.9
2.4
5975
25.7
7.8
0.7
1.7
34.3
10.5
0.9
2.2
