Rockwell Automation 20D PowerFlex 700H and 700S Frame 9...14 Drives User Manual
Page 80
80
Rockwell Automation Publication PFLEX-IN006E-EN-P - July 2013
Chapter 6
Frame 10 Mechanical Installation
Figure 25 - Common Mode Jumper and Rectifier Circuit Board Location
Common Mode
jumper
Rectifier Circuit Board
Front View of
Assembly
There is one common mode
jumper located on the upper-
right side of the power structure.
Control Frame not shown for clarity only.
