Specifications Appendix A
Table 14 - 650 Volt DC Input Frames 9…14 Drive Protection Devices
20xH1K4 13 800 - 1707 2400 170M7107
- 710 1413 2400 170M7107
20xH1K7 (1) 14 1000 - 2084 – 170M8610
- 900 1883 – 170M8610
20xH2K1 (1) 14 1200 - 2531 – 170M8610
- 1100 2284 – 170M8610
20xH2K7
(1)
14 1600 - 3178 – 170M8610
- 1300 2708 – 170M8610
(1) Not available with 700S Control.
Drive Catalog Number Frame HP Rating DC Input Ratings Fuse Bussmann Style Fuse
ND HD Amps
20xJ261 9 200 - 294 500 170M6608
- 150 231 500 170M6608
20xJ300 9 250 - 338 630 170M6610
- 200 294 630 170M6610
20xJ385 10 300 - 434 700 170M6611
- 250 338 700 170M6611
20xJ460 10 350 - 519 900 170M6613
- 300 434 900 170M6613
20xJ500 10 450 - 564 500 (2 per phs) 170M6608
- 350 474 500 (2 per phs) 170M6608
20xJ590 11 500 - 666 550 (2 per phs) 170M6609
- 450 587 550 (2 per phs) 170M6609
20xJ650 11 500 - 733 630 (2 per phs) 170M6610
- 500 666 630 (2 per phs) 170M6610
20xJ730 11 600 - 824 700 (2 per phs) 170M6611
- 500 733 700 (2 per phs) 170M6611
20xJ820 12 700 - 925 700 (2 per phs) 170M6611
- 600 824 700 (2 per phs) 170M6611
20xJ920 12 800 - 1038 550 (3 per phs) 170M6609
- 700 925 550 (3 per phs) 170M6609
20xJ1K0 12 900 - 1162 630 (3 per phs) 170M6610
- 800 1038 630 (3 per phs) 170M6610
20xJ1K1 13 1000 - 1297 2400 170M7107
- 900 1162 2400 170M7107
20xJ1K3 13 1200 - 1467 2400 170M7107
- 1000 1297 2400 170M7107
20xJ1K4 13 1250 - 1636 2400 170M7107
- 1000 1354 2400 170M7107
20xJ1K7
(1)
(1) Not available with 700S Control.
14 1500 - 1997 – 170M8610
- 1400 1805 – 170M8610
20xJ2K1
(1)
14 1900 - 2425 – 170M8610
- 1700 2189 – 170M8610
20xJ2K7
(1)
14 2300 - 3046 – 170M8610
- 2000 2595 – 170M8610
Drive Catalog Number Frame kW Rating DC Input Ratings Fuse Bussmann Style Fuse
ND HD Amps
