Frame 12 Mechanical Installation
Figure 38 - Enclosure Code B (NEMA/UL Type 1, IP21) and K (NEMA/UL Type 1, IP21 w/Conformal
Coat)
Operating Temperatures
Frame 12 drives require a minimum of 5200 m
3
/h (3060 cfm) of cooling air.
200 mm
(8.0 in.) Min.
Powerf
u
l Perform
a
nce, Flexi
b
le Control.
838 mm
(33.0 in.) Min.
Powerf
u
l Perform
a
nce, Flexi
b
le Control.
PowerFlex
Drive
Voltage Class
Amp Rating
Surrounding Air Temperature
Normal Duty
Heavy Duty
700H
400/480V AC
(540/650V DC)
820, 920
0…40
°
C (32…104
°
F)
0…40
°
C (32…104
°
F)
400/480V AC
(540/650V DC)
1030
0…40
°
C (32…104
°
F)
0…35
°
C (32…95
°
F)
600/690V AC
(810/932V DC)
820, 920
0…40
°
C (32…104
°
F)
0…40
°
C (32…104
°
F)
600/690V AC
(810/932V DC)
1030
0…35
°
C (32…95
°
F
0…40
°
C (32…104
°
F)
700S
400/480V AC
(540/650V DC)
820, 920
0…40
°
C (32…104
°
F)
0…40
°
C (32…104
°
F)
400/480V AC
(540/650V DC)
1030
0…40
°
C (32…104
°
F)
0…35
°
C (32…95
°
F
600/690V AC
(810/932V DC)
820, 920
0…40
°
C (32…104
°
F)
0…40
°
C (32…104
°
F)
600/690V AC
(810/932V DC)
1030
0…35
°
C (32…95
°
F
0…35
°
C (32…95
°
F
