188 Rockwell Automation Publication PFLEX-IN006E-EN-P - July 2013
Appendix B PowerFlex 700S Stegmann Hi-Resolution Encoder Feedback Option
Figure 4 - MPL-A5xx and all MPL-Bxxx motors or 1326AB-BXXXX-M2L, -M2KXL, -S2L, and -S2KXL motors with 2090-CDNFDMP-SXX cable
Figure 5 - MPL-A5xx and all MPL-Bxxx Motor or 1326AB-BXXXX-M2L, -M2KXL, -S2L, and -S2KXL motor with 2090-XXNFMP-SXX cable
Note: Thermal Switch cannot be accessed using 2090-XXNFMP-SXX cable.
Figure 6 - MPL-A3xx - MPL-A45xx and all MPG series motors with 2090-XXNFMP-SXX cable
Note: Thermal Switch cannot be accessed using 2090-XXNFMP-SXX cable.
Connection Examples
+SIN
REFSIN
+COS
REFCOS
DATA+ (RS-485)
DATA- (RS 485)
POWER
COMMON
TS+
TS-
A
B
C
D
E
F
N
P
R
S
BK
BK/WH
RD
WH/RD
GN
WH/GN
OR
WH/OR
BU
WH/BU
BK
BK/WH
RD
WH/RD
GN
WH/GN
OR
WH/OR
BU
WH/BU
12
11
10
9
8
7
6
5
4
3
2
1
POWER COMMON
POWER
N/C
N/C
+SIN
REFSIN
+COS
REFCOS
SHIELD
SHIELD
DATA+ (RS 485)
DATA- (RS 485)
Hi-Res Feedback Option Board ENCODER
+SIN
REFSIN
+COS
REFCOS
DATA+ (RS-485)
DATA- (RS 485)
POWER
COMMON
TS+
TS-
A
B
C
D
E
F
N
P
R
S
BK
WH/BK
RD
WH/RD
GN
WH/GN
OR
WH/GY
BK
WH/BK
RD
WH/RD
GN
WH/GN
OR
WH/GY
12
11
10
9
8
7
6
5
4
3
2
1
POWER COMMON
POWER
N/C
N/C
+SIN
REFSIN
+COS
REFCOS
SHIELD
SHIELD
DATA+ (RS 485)
DATA- (RS 485)
Hi-Res Feedback Option Board ENCODER
+SIN
REFSIN
+COS
REFCOS
DATA+ (RS-485)
DATA- (RS 485)
POWER
COMMON
TS+
TS-
A
B
C
D
E
F
K
L
R
S
BK
BK/WH
RD
WH/RD
GN
WH/GN
GY
WH/GY
BK
BK/WH
RD
WH/RD
GN
WH/GN
GY
WH/GY
12
11
10
9
8
7
6
5
4
3
2
1
POWER COMMON
POWER
N/C
N/C
+SIN
REFSIN
+COS
REFCOS
SHIELD
SHIELD
DATA+ (RS 485)
DATA- (RS 485)
Hi-Res Feedback Option Board ENCODER
