Rockwell Automation Publication PFLEX-IN006E-EN-P - July 2013 169
Specifications Appendix A
Table 3 - 600 Volt AC Input Frames 9…14 Drive Ratings
Drive
Catalog
Number
Fram
e
HP Rating PWM
Freq. Temp. Input
Ratings Output Amps Watts
Loss
ND HD kHz
°
C Amps Cont. 1 Min. 3 Sec. Watts
20xE170 9 150 – (3)
(3) Rated PWM for 700H control 1.5kHz, Rated PWM for 700S control 2.0kHz.
40 164 170 187 245 –
– 150 (3) 40 139 144 216 245 –
20xE208 9 200 – (3) 35 201 208 230 289 –
– 150 (3) 40 164 170 250 289 –
20xE261 10 250 – (3) 40 252 261 287 375 4206
– 200 (3) 40 201 208 312 375 4206
20xE325 10 350 – (3) 40 314 325 358 470 4751
– 250 (3) 40 252 261 392 470 4751
20xE385 10 400 – (3) 40 372 385 424 585 5527
– 350 (3) 40 314 325 488 585 5527
20xE416 10 450 – (3) 35 402 416 458 585 5622
– 350 (3) 40 314 325 488 585 5622
20xE460 11 500 – (3) 40 444 460 506 693 6345
– 400 (3) 40 372 385 578 693 6345
20xE502 11 500 – (3) 40 485 502 552 828 6925
– 500 (3) 40 444 460 690 828 6925
20xE590 11 600 – (3) 35 570 590 649 885 7539
– 500 (3) 35 485 502 753 904 7539
20xE650 12 700 – (3) 40 628 650 715 1062 9502
– 650 (3) 40 570 590 885 1062 9502
20xE750 12 800 – (3) 40 724 750 825 1170 10570
– 700 (3) 40 628 650 975 1170 10570
20xE820
(1)
(1) 20DE820 drives (ND) are only capable of producing 95% of starting torque under 10 Hz.
12 900 – (3) 35 792 820 902 1170 11082
– 700 (3) 35 628 650 975 1170 11082
20xE920 13 1000 – (3) 40 888 920 1012 1380 12690
– 900 (3) 40 792 820 1230 1410 12690
20xE1K0 13 1100 – (3) 40 994 1030 1133 1545 15907
– 1000 (3) 40 888 920 1380 1755 15907
20xE1K1 13 1300 – (3) 35 1139 1180 1298 1755 17306
– 1100 (3) 35 994 1030 1463 1755 17306
20xE1K5 14 1600 – (3) 40 1448 1500 1650 2250 22500
– 1400 (3) 40 1255 1300 1950 2340 22500
20xE1K9
(2)
(2) Not available with 700S Control.
14 2000 – (3) 40 1834 1900 2090 2700 28500
– 1600 (3) 40 1448 1500 2250 2700 28500
20xE2K2
(2)
14 2400 – (3) 30 2172 2250 2475 3335 33400
– 2000 (3) 30 1834 1900 2782 3335 33400
