Specifications
Appendix A
Table 5 - 540 Volt DC Input Frames 9…14 Drive Ratings
Drive Catalog
Number
Fr
am
e kW Rating
PWM Freq.
Temp.
DC Input Ratings
Output Amps
ND
HD
kHz
°
C
Amps
Cont.
1 Min.
3 Sec.
20xH261
9
132
-
2
40
307
261
287
410
-
110
2
40
241
205
308
410
20xH300
9
160
-
2
40
353
300
330
450
-
132
2
40
288
245
368
490
20xH385
10 200
-
2
40
453
385
424
600
-
160
2
40
353
300
450
600
20xH460
10 250
-
2
40
541
460
506
770
-
200
2
40
453
385
578
770
20xH500
10 250
-
2
40
589
500
550
750
-
250
2
40
494
420
630
840
20xH590
11 315
-
2
40
695
590
649
956
-
250
2
40
612
520
780
956
20xH650
11 355
-
2
40
765
650
715
1062
-
315
2
40
695
590
885
1062
20xH730
11 400
-
2
40
859
730
803
1095
-
355
2
40
765
650
975
1170
20xH820
12 450
-
2
40
965
820
902
1230
-
400
2
40
859
730
1095
1314
20xH920
12 500
-
2
40
1083
920
1012
1380
-
450
2
40
965
820
1230
1476
20xH1K0
12 560
-
2
40
1213
1030
1133
1555
-
500
2
35
1083
920
1370
1600
20xH1K1
13 630
-
2
40
1354
1150
1265
1620
-
560
2
40
1213
1030
1545
1620
20xH1K3
13 710
-
2
40
1530
1300
1430
2079
-
630
2
40
1354
1150
1725
2079
20xH1K4
13 800
-
2
40
1707
1450
1595
2175
-
710
2
40
1413
1200
1800
2400
20xH1K7
(1)
(1) Not available with 700S Control.
14 1000
-
2
40
2084
1770
1947
2655
-
900
2
40
1883
1600
2400
2880
20xH2K1
(1)
14 1200
-
2
40
2531
2150
2365
3225
-
1100
2
40
2284
1940
2910
3492
20xH2K7
(1)
14 1600
-
2
40
3178
2700
2970
3933
-
1300
2
40
2708
2300
3287
3933
