Rockwell Automation 20D PowerFlex 700H and 700S Frame 9...14 Drives User Manual
Page 168
168
Rockwell Automation Publication PFLEX-IN006E-EN-P - July 2013
Appendix A
Specifications
Table 2 - 480 Volt AC Input Frames 9…14 Drive Ratings
Drive
Catalog
Number
Fram
e
HP Rating
PWM
Freq.
Temp.
Input
Ratings
Output Amps
Watts
Loss
ND
HD
kHz
°
C
Amps
Cont.
1 Min.
3 Sec.
Watts
20xD261
9
200
-
2
40
252
261
287
410
2700
-
150
2
40
207
205
308
410
2700
20xD300
9
250
-
2
40
290
300
330
450
3100
-
200
2
40
247
245
368
490
3100
20xD385
10 300
-
2
40
372
385
424
600
4320
-
250
2
40
302
300
450
600
4320
20xD460
10 350
-
2
40
444
460
506
770
5335
-
300
2
40
388
385
578
770
5335
20xD500
10 450
-
2
40
483
500
550
750
5921
-
350
2
40
423
420
630
840
5921
20xD590
11 500
-
2
40
570
590
649
956
6620
-
450
2
40
524
520
780
956
6620
20xD650
11 500
-
2
40
628
650
715
1062
7538
-
500
2
40
594
590
885
1062
7538
20xD730
11 600
-
2
40
705
730
803
1095
8312
-
500
2
40
655
650
975
1170
8312
20xD820
12 700
-
2
40
792
820
902
1230
9201
-
600
2
40
735
730
1095
1314
9201
20xD920
12 800
-
2
40
888
920
1012
1380
10670
-
700
2
40
826
820
1230
1476
10670
20xD1K0
12 900
-
2
40
994
1030
1133
1555
11729
-
800
2
35
927
920
1370
1600
11729
20xD1K1
13 1000
-
2
40
1110
1150
1265
1620
13801
-
900
2
40
994
1030
1545
1620
13801
20xD1K3
13 1200
-
2
40
1255
1300
1430
2079
15077
-
1000
2
40
1110
1150
1725
2079
15077
20xD1K4
13 1250
-
2
40
1400
1450
1595
2175
16511
-
1000
2
40
1158
1200
1800
2400
16511
20xD1K7
(1)
(1) Not available with 700S Control.
14 1500
-
2
40
1709
1770
1947
2655
24800
-
1400
2
40
1545
1600
2400
2880
24800
20xD2K1
(1)
14 1900
-
2
40
2076
2150
2365
3225
29900
-
1700
2
40
1873
1940
2910
3492
29900
20xD2K7
(1)
14 2300
-
2
40
2607
2700
2970
3933
39680
-
2000
2
40
2220
2300
3287
3933
39680
