Appendix F History of Changes
PFLEX-IN006D-EN-P,
March 2006
Change
Updated the Normal Duty power ratings
Updated the Reference Materials List
Added information on installations using single-phase input power
Updated the Common Bus/Precharge information
Added a description for the use of output reactors on frame 14 drives
Updated the 700H I/O board options chart
Updated the “Auto/Manual Notes” section to include information on enabling manual mode to allow starts and jogs
from the HIM in 2-wire mode
Added a note to the analog inputs on the 700S Phase II control
Added terminal wiring illustration for external brake resistor and external brake IGBT and resistor connections on frame
9 drives
Updated all Frame 10 dimension drawings to include cable routing information.
Added a dimension drawing for the frame 10 Motor Control Center (MCC), Enclosure Codes “B” and “K”
Updated the instructions for frame 10 Ungrounded, High Resistive Ground or Grounded B Phase Delta installations
Updated the Power Terminal Block designations for frame 10 (removed brake option terminals)
Updated all Frame 11 dimension drawings to include cable routing information.
Added a dimension drawing for the frame 11 Motor Control Center (MCC), Enclosure Codes “B” and “K”
Updated the instructions for frame 11 Ungrounded, High Resistive Ground or Grounded B Phase Delta installations
Updated all Frame 12 dimension drawings to include cable routing information.
Added a dimension drawing for the frame 12 Motor Control Center (MCC), Enclosure Codes “B” and “K”
Updated the instructions for frame 12 Ungrounded, High Resistive Ground or Grounded B Phase Delta installations
Updated all Frame 13 dimension drawings to include cable routing information.
Updated the frame 13 dimensions for the NEMA/UL Type 12 - IP54 Enclosures
Updated the instructions for frame 13 Ungrounded, High Resistive Ground or Grounded B Phase Delta installations
Added Chapter 11 - Frame 14 Installation
Updated the Agency Certification information for drives with 700H control
Separated the drive ratings information from the drive protection devices - now in separate tables
Updated the drive rating, fusing and circuit breaker specifications
Added new Appendix B to consolidate the common lifting and mounting instructions
Added the Allen-Bradley 842HR rotary encoder to the list of compatible encoders
Updated wiring diagrams for the Hi-Resolution Encoder
Updated wiring diagrams for Resolvers
Updated wiring diagrams for the MDI board
Added Appendix E on ATEX Approved PowerFlex 700H Drives in Group II Category (2) Applications with ATEX Approved
Motors
