122 Rockwell Automation Publication PFLEX-IN006E-EN-P - July 2013
Chapter 9 Frame 13 Mechanical Installation
Figure 49 - Enclosure Code H (NEMA/UL Type 12, IP54) and W (NEMA/UL Type 12, IP54 w/Conformal
Coat)
Table 28 - Frame 13 Dimensions for Enclosure Code H (NEMA/UL Type 12 - IP54) and W (NEMA/UL
Type 12, IP54 w/Conformal Coat)
F
65
(2.6)
535
(21.1)
H Ø 13 (0.5)
2 Places
E
D
B
122
(4.8)
454
(17.8)
662
(26.1)
A
C
G
NEMA/UL Type
12 Roof
Assembly
NEMA/UL
Type 12
External
Filters
Wire entry for this enclosure is
between two pieces of soft foam. If
the adjustable plate is slid back, a
gap develops between the foam
pieces. otherwise, the foam acts as a
loose gasket around the wires.
Stationary metal front bottom plate
Two pieces of soft foam taped to adjacent metal plates
Overlapping metal bottom plate (slightly adjustable)
Stationary metal back bottom plate
Voltage Class Amps A B C D E F G H
400/480V AC
(540/650V DC) 1150 1412 (56) 478 (18.8) 678 (26.7) 1 @ 242 (9.5)
1 @ 213 (8.4) 2443.5 (104.5)
max.
535 (21) 735 (29) 1264 (50)
1300 1600 (63) 678 (26.7) 678 (26.7) 2 @ 242 (9.5) 2443.5 (104.5) 735 (29) 735 (29) 1464 (58)
1450
600/690V AC
(810/932V DC) 920 1412 (56) 478 (18.8) 678 (26.7) 1 @ 242 (9.5)
1 @ 213 (8.4) 2443.5 (104.5)
max.
535 (21) 735 (29) 1264 (50)
1030
1180
Dimensions are in millimeters and (inches).
