Appendix A Specifications
Table 15 - 810 Volt DC Input Frames 9…14 Drive Protection Devices
Drive Catalog Number Frame HP Rating DC Input Ratings Fuse Bussmann Style Fuse
ND HD Amps
20xK170 9 150 – 192 400 170M5608
– 150 162 400 170M5608
20xK208 9 200 – 235 450 170M5609
– 150 192 450 170M5609
20xK261 10 250 – 294 450 170M5609
– 200 235 450 170M5609
20xK325 10 350 – 367 550 170M6609
– 250 294 550 170M6609
20xK385 10 400 – 434 700 170M6611
– 350 367 700 170M6611
20xK416 10 450 – 469 800 170M6612
– 350 367 800 170M6612
20xK460 11 500 – 519 450 (2 per phs) 170M5609
– 400 434 450 (2 per phs) 170M5609
20xK502 11 500 – 566 500 (2 per phs) 170M6608
– 500 519 500 (2 per phs) 170M6608
20xK590 11 600 – 666 500 (2 per phs) 170M6608
– 500 566 500 (2 per phs) 170M6608
20xK650 12 700 – 733 500 (2 per phs) 170M6608
– 650 666 500 (2 per phs) 170M6608
20xK750 12 800 – 846 630 (2 per phs) 170M6610
– 700 733 630 (2 per phs) 170M6610
20xK820
(1)
(1) 20DK820 drives (ND) are only capable of producing 95% of starting torque under 10 Hz.
12 900 – 925 630 (2 per phs) 170M6610
– 700 733 630 (2 per phs) 170M6610
20xK920 13 1000 – 1038 2400 170M7107
– 900 925 2400 170M7107
20xK1K0 13 1100 – 1162 2400 170M7107
– 1000 1038 2400 170M7107
20xK1K1 13 1300 – 1331 2400 170M7107
– 1100 1162 2400 170M7107
20xK1K5 14 1600 – 1692 – 170M8610
– 1400 1467 – 170M8610
20xK1K9
(2)
(2) Not available with 700S Control.
14 2000 – 2143 – 170M8610
– 1600 1692 – 170M8610
20xK2K2
(2)
14 2400 – 2538 – 170M8610
– 2000 2143 – 170M8610
