Rockwell Automation Publication PFLEX-IN006E-EN-P - July 2013
167
Specifications
Appendix A
Drive Catalog Number
Designations
The first three characters of the drive catalog numbers in the drive ratings and
protection devices tables on the following pages designate the type of drive
control. The information in the tables are valid for PowerFlex drives with both
the 700H and 700S control. Therefore, the third character of the drive catalog
number in each table is replaced with an “x”. For ordering purposes, drives with
the 700H control are designated as “20C” and drives with the 700S control are
designated as “20D”.
Drive Ratings
The tables on the following pages provide drive ratings (including continuous, 1
minute and 3 seconds), PWM frequency ratings, ambient operating temperatures
and watts loss information.
Table 1 - 400 Volt AC Input Frames 9…14 Drive Ratings
Drive Catalog
Number
Fram
e
kW Rating
PWM
Freq.
Temp.
Input
Ratings
Output Amps
Watts
Loss
ND
HD
kHz
°
C
Amps
Cont.
1 Min.
3 Sec.
Watts
20xC261
9
132
-
2
40
263
261
287
410
2700
-
110
2
40
207
205
308
410
2700
20xC300
9
160
-
2
40
302
300
330
450
3100
-
132
2
40
247
245
368
490
3100
20xC385
10
200
-
2
40
388
385
424
600
4320
-
160
2
40
302
300
450
600
4320
20xC460
10
250
-
2
40
463
460
506
770
5335
-
200
2
40
388
385
578
770
5335
20xC500
10
250
-
2
40
504
500
550
750
5921
-
250
2
40
423
420
630
840
5921
20xC590
11
315
-
2
40
594
590
649
956
6620
-
250
2
40
524
520
780
956
6620
20xC650
11
355
-
2
40
655
650
715
1062
7538
-
315
2
40
594
590
885
1062
7538
20xC730
11
400
-
2
40
735
730
803
1095
8312
-
355
2
40
655
650
975
1170
8312
20xC820
12
450
-
2
40
826
820
902
1230
9201
-
400
2
40
735
730
1095
1314
9201
20xC920
12
500
-
2
40
927
920
1012
1380
10670
-
450
2
40
826
820
1230
1476
10670
20xC1K0
12
560
-
2
40
1038
1030
1133
1555
11729
-
500
2
35
927
920
1370
1600
11729
20xC1K1
13
630
-
2
40
1158
1150
1265
1620
13801
-
560
2
40
1038
1030
1545
1620
13801
20xC1K3
13
710
-
2
40
1310
1300
1430
2079
15077
-
630
2
40
1158
1150
1725
2079
15077
20xC1K4
13
800
-
2
40
1461
1450
1595
2175
16511
-
710
2
40
1209
1200
1800
2400
16511
20xC1K7
(1)
(1) Not available with 700S Control.
14
1000
-
2
40
1783
1770
1947
2655
24800
-
900
2
40
1612
1600
2400
2880
24800
20xC2K1
(1)
14
1200
-
2
40
2166
2150
2365
3225
29900
-
1100
2
40
1954
1940
2910
3492
29900
20xC2K7
(1)
14
1600
-
2
40
2720
2700
2970
3933
39680
-
1300
2
40
2317
2300
3287
3933
39680
