REPLACEMENT PARTS and ACCESSORIES
FlexPak 3000 49’1340 e 8-4
Table 8-3: Urgent recommended spare parts for 1-Quadrant units S-6 250 / 450 and 800 A
Thyristor/ Field Rectifier P.C. Boards,
Power Unit Type Thyristor- Module with MOV MOV-Module Cooling Fan
Module
250 A 848.06.03/73 3 Modules 1 Module 1 Regulator 810.79.40 1 Fan
135.11.02 124.07.00 with Firmware EPROM 921.90.00
1 MOV 1 Interface TIF 813.42.01
450 A 848.08.03/73 3 Modules
123.39.30
1 Power Supply FPP 810.89.00
135.12.02 1 Field Current Regul. 762.70.60*
1 MOV-Module 123.43.04
800 A 848.10.03/73 6 Thyristors 1 Regulator 810.79.40
122.04.02 with Firmware EPROM
1 Interface TIF 813.42.01
1 Power Supply FPP 810.89.00
1 Field Current Regul. 762.70.70*
1 MOV-Module 123.43.04
* The Field Current Regulator is only included i n FlexPak types 848.xx.73.
Table 8-4: Urgent recommended spare parts for 4-Quadrant units S-6R 250 / 450 and 800 A
Thyristor/ Field Rectifier P.C. Boards,
Power Unit Type Thyristor- Module with MOV MOV-Module Cooling Fan
Module
250 A 848.07.03/73 6 Modules 1 Module 1 Regulator 810.79.40 1 Fan
135.11.02 124.07.00 with Firmware EPROM 921.90.00
1 MOV 1 Interface TIE 813.42.00
450 A 848.09.03/73 6 Modules
123.39.30
1 Power Supply FPP 810.89.00
135.12.02 1 Field Current Regul. 762.70.60*
1 MOV-Module 123.43.04
800 A 848.11.03/73 12 Thyristors 1 Regulator 810.79.40
122.04.02 with Firmware EPROM
1 Interface TIE 813.42.00
1 Power Supply FPP 810.89.00
1 Field Current Regul. 762.70.70*
1 MOV-Module 123.43.04
* The Field Current Regulator is only included i n FlexPak types 848.xx.73
Further spare parts:
Unit Type
250 / 450 A 1 Capacitor 211.00.05 1 Resistor 425.18.18
800 A: 1 Capacitor 211.36.05 2 Resistor 425.18.18
