QUICK START
49’1340 e FlexPak 3000 6-1
6.0 Quick Start
ATTENTION:
Only qualified electrical personnel familiar with the construction and operation of this equipment and
the hazards involved should install, adjust, operate and/or service this equipment. Read and
understand this section in its entirety before proceeding. Failure to observe this precaution could result
in bodily injury or loss of life.
6.1 Introduction
The Quick Start function from the Main Menu will be used to start up and tune the drive.
NOTE: CONTROL SOURCE SELECT must be set to KEYPAD for complete OIM control during
the Quick Start procedure.
6.2 About The Quick Start Exit Menu
Pressing CANCEL during the Quick Start procedure (except where noted) will cause the Quick
Start Exit Menu to be displayed.
For example:
Quick Start
Quick Start Exit Menu
" Return to previous step.
Exit Quick Start using changes.
Exit Q.S. without using changes.
!!
!!
Fault
Alarm
Interlock OK
Drive Ready
Running
Current Limit
Torque Limit
PROGRAM KEYPAD MANUAL FORWARD
The user must pick one of the options from the Quick Start Exit Menu. Repeatedly pressing
CANCEL and selecting "Return to previous step" allows the user to go backward through the
Quick Start procedure.
6.3 How To Step Through Quick Start
ATTENTION:
The drive will not operate at the correct speed if hardware jumpers J11, J14 and J18 are not set as
indicated on the OIM during Quick Start. Record and verify that these jumpers are set as indicated on
the OIM during Quick Start. Failure to observe this precaution could result in damage to, or destruction
of, the equipment.
Record the present values of J11, J14 and J18 in Table 6.1 before continuing with this
procedure. The correct position of these jumper settings will be displayed during the "Quick
Start" procedure. If the correct position of these jumpers are the same as the values recorded in
Table 6.1, Self Tuning can be started without leaving the Quick Start screens. If they are not the
same, refer to section 4.5, Jumper Settings.
