APPENDIX G
49’1340 e FlexPak 3000 G-5
Table G.1 - User Quick Reference Table for Input Parameters (continued)
Par. Parameter Parameter Selection / Pg Initial Factory User Data
No. Adjustment Range B- Setting Date Setting
Digital Outputs Set-up (on I/O card)
409 DIG OUT 1 SELECT • LEVEL DETECT 1 OUTPUT
• LEVEL DETECT 2 OUTPUT
• IN CURRENT LIMIT
• DRIVE READY
• NETW COMM STATUS
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
13 LEVEL
DETECT 1
OUTPUT
410 DIG OUT 1 CONTACT TYP • NORMAL OPEN
• NORMAL CLOSED
13 NORMAL
OPEN
411 DIG OUT 2 SELECT • LEVEL DETECT 1 OUTPUT
• LEVEL DETECT 2 OUTPUT
• IN CURRENT LIMIT
• DRIVE READY
• NETW COMM STATUS
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
14 LEVEL
DETECT 2
OUTPUT
412 DIG OUT 2 CONTACT TYP • NORMAL OPEN
• NORMAL CLOSED
13 NORMAL
OPEN
Analog Inputs / Outputs (on I/O card)
413 ANLG IN 1 SIG TYPE • 0-10V, ±10V
• 4-20 mA, 10-50 mA
3 ±10 V
414 ANLG IN 1 ZERO ADJ -200 - 200 3 0
415 ANLG IN 1 GAIN ADJ 0.750 - 2.250 3 1.000
416 ANLG IN 2 ZERO ADJ -200 - 200 4 0
417 ANLG IN 2 GAIN ADJ 0.750 - 2.250 4 1.000
418 ANLG OUT 1 SELECT • CML FEEDBACK
• CML REFERENCE
• CML ERROR
• SPD LOOP FEEDBACK
• SPD LOOP REFERENCE
• SPD LOOP ERROR
• SPD LOOP OUTPUT
• SPEED RAMP OUTPUT
• SPEED RAMP INPUT TP
• SPD SOURCE SELECT OUT
• TRIM OUTPUT
• ARMATURE VOLTAGE
• ANALOG TACH FEEDBACK
• PULSE TACH FEEDBACK
• ZERO
• FULL SCALE
• POWER OUTPUT
• OCL REFERENCE
• OCL RAMP OUTPUT
• OCL FEEDBACK
• OCL OUTPUT
• FIELD REFERENCE
• FIELD FEEDBACK
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
5 ZERO
