SPD LOOP PI INIT SEL (Alternate network map, Drop_2, register 32)
Only available if the AutoMax Network Communication board is installed.
Selects the Speed Loop PI block initial value source when CONTROL SOURCE SELECT = Network.
NOTE: SPD LOOP PI INIT VAL is forced to ZERO when CONTROL SOURCE SELECT
≠
Network.
Parameter Range:
0=
ZERO
1= SPD LOOP PI INIT VAL
2= ANALOG MAN TRIM REF
Default Setting:
0
Parameter Type:
Configurable
OIM Menu Path(s):
N/A, network only
Refer also to Parameters:
CONTROL SOURCE SELECT (P.000)
ANALOG MAN TRIM REF (P.194)
SPD LOOP PI INIT VAL (Alternate network map, Drop_1, register 39)
SPD LOOP PI INIT SEL (Alternate network map, Drop_2, register 32)
SPD LOOP PI INIT VAL (Alternate network map, Drop_1, register 39)
Only available if the AutoMax Network Communication board is installed.
Network initial value for the Speed Loop PI block.
Parameter Range:
-32768 - 32767
Default Setting:
0
Parameter Type:
Tuneable
OIM Menu Path(s):
N/A, network only
Refer also to Parameters:
CONTROL SOURCE SELECT (P.000)
SPD LOOP PI RESET (Alternate network map, Drop_1, register 32, Bit 6)
SPD LOOP PI PROP GAIN (P.211)
Speed loop PI block proportional gain.
Parameter Range:
0.10 to 128.00
Default Setting:
4.40
Parameter Type:
Tuneable
OIM Menu Path(s):
Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Tuning
SPD LOOP PI RESET (Alternate network map, Drop_1, register 32, Bit 6)
Only available if the AutoMax Network Communication board is installed. When asserted, the Speed
Loop PI block is held in Reset with the initial value appearing at the PI block output.
Parameter Range:
0 = ENABLE
1 = RESET
Default Setting:
1
Parameter Type:
Tuneable
OIM Menu Path(s):
N/A, network only
Refer also to Parameters:
CONTROL SOURCE SELECT (P.000)
SPD LOOP PI INIT SEL (Alternate network map, Drop_2, register 32)
SPD LOOP PI INIT VAL (Alternate network map, Drop_1, register 39)
