INTRODUCTION TO THE DRIVE
49’1340 e FlexPak 3000 2-11
FlexPak 3000 Main Menu
!!
"Quick Start
Drive Reference
Speed/Voltage Loop (SPD)
#Current Minor Loop (CML)
PROGRAM KEYPAD MANUAL FORWARD
•
Pressing this key will display the following screen:
MOTOR SPEED 0 RPM
ARM VOLTS 0 VOLTS
MOTOR LOAD 0 %FLA
KEYPAD REF: 0 RPM
!!
MONITOR KEYPAD MANUAL FORWARD
This screen allows the user to change the drive's setpoint (KEYPAD REF) when the CONTROL
SOURCE SELECT is set to KEYPAD and the drive is in manual mode. Use the up/down arrow
keys to change the drive's setpoint. Pressing the ENTER key will save the setpoint to non-volatile
memory.
•
Pressing the PROGRAM/MONITOR key a second time will display motor speed (RPM) and
motor load (FLA):
0 RPM
0 %FLA
!!
MONITOR KEYPAD MANUAL FORWARD
This screen does not allow the user to change the drive's setpoint (KEYPAD REF).
•
Pressing the PROGRAM/MONITOR key after the second time will re-display the previous
PROGRAM display (the first screen in this example).
Pressing the ENTER key will save the setpoint to non-volatile memory.
Pressing the CANCEL key when in monitor mode will return the OIM to the PROGRAM mode.
Table 2.6 lists drive parameters monitored and reported to the OIM.
Table 2.6 - Drive Monitor Capabilities
Monitor List Selectable Engineering Units
Motor Speed Percent, RPM, Units*
Arm Volts (Armature Voltage) Volts
Motor Load (Armature Current) Percent Full Load Amps (%FLA), Amps
TERMBLK REF, KEYPAD REF
or TORQUE REF**, NETWORK REF*** Percent, RPM, Units*
* Units: Indicates the user's option to select an engineering unit (6 characters maximum) for readout to display. A number
from 1 to 10,000 full scale can be assigned a meaningful value (e.g. FPM, Feet Per Minute, etc.). See "Define User
Units" in Section 4.
** When the drive is configured as a current (torque) regulator (J15 Hardware Jumper = CURRENT), the Control Source
Select (CSS) can only be set to TERMBLK or NETWORK (if option is installed). In this case, TORQUE REF or
NETWORK REF is displayed. The units are the same as displayed for MOTOR LOAD.
** When the drive is configured as a speed or armature voltage regulator (J15 Hardware Jumper = SPEED),
the selected control source determines the reference source (TERMBLK REF or KEYPAD REF, or NETWORK REF).
*** Available with an optional Network Communication Board.
