APPENDIX G
FlexPak 3000 49’1340 e G-4
Table G.1 - User Quick Reference Table for Input Parameters (continued)
Par. Parameter Parameter Selection / Pg Initial Factory User Data
No. Adjustment Range B- Setting Date Setting
Current Regulator Set-up
300 CML FEEDBACK GAIN ADJ 0.900 - 1.100 9 1.000
301 CML PI PROP GAIN 0.000 - 4.000 9 0.250
302 CML PI LEAD FREQ 10 - 500 rad/s 9 100 rad/s
303 CML REF RATE LIMIT 1 - 1000 msec 10 40 msec
306 NOMINAL AC LINE FREQ 48 - 62 Hz 36 50 Hz
307 NOMINAL AC LINE VOLTS 200 - 575 VAC or
300 - 850 VAC (types 575/690 V) 36 400 VAC
308 PLL MAXIMUM ERROR 2 - 1000 µsec 42 2 µsec
309 PHASE FIRE TEST DELTA 0 - 180 degrees 41 0 degrees
310 PHASE FIRE TST BRIDGE • OFF
• ON
42 OFF
311 CML REF LIMIT SELECT • 1 = SPD LOOP PI LIMITS
• 2 = REGISTER
10 1
312 INV FAULT AVOID SEL • 1 = DISABLED
• 2 = FAULT IMMEDIATELY
• 3 = DELAY BEFORE FAULT
21 DISABLED
Meter Outputs Set-up
400 METER OUT 1 GAIN ADJ 0.100 - 1.900 26 1.000
401 METER OUT 2 GAIN ADJ 0.100 - 1.900 28 1.000
402 METER OUT 1 ZERO ADJ -200 - +200 27 0
403 METER OUT 2 ZERO ADJ -200 - +200 28 0
404 METER OUT 1 SELECT • CML FEEDBACK
• CML REFERENCE
• CML ERROR
• SPD LOOP FEEDBACK
• SPD LOOP REFERENCE
• SPD LOOP ERROR
• SPD LOOP OUTPUT
• SPEED RAMP OUTPUT
• SPEED RAMP INPUT TP
• SPD SOURCE SELECT OUT
• TRIM OUTPUT
• ARMATURE VOLTAGE
• ANALOG TACH FEEDBACK
• PULSE TACH FEEDBACK
• ZERO
• FULL SCALE
• POWER OUTPUT
• OCL REFERENCE
• OCL RAMP OUTPUT
• OCL FEEDBACK
• OCL OUTPUT
• FIELD REFERENCE
• FIELD FEEDBACK
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
27 CML
FEEDBACK
405 METER OUT 2 SELECT
same as above for P.404
28 SPD LOOP
FEEDBACK
