TROUBLESHOOTING/DIAGNOSTICS
FlexPak 3000 49’1340 e 7-2
7.5 Remote M Contactor
If an M Contactor has been supplied by others, verify that it has been properly connected.
7.6 Optional Kits
Verify that each optional kit has been installed correctly according the appropriate instructions.
Refer to the appropriate instruction manuals.
7.7 Fault/Alarm/Diagnostic (FAD) Menus
The OIM FAULT key toggles the FAD menus (see Section 2:). FAD menus are provided to
assist in the analysis of drive operation problems. Refer to Appendix E for a complete guide to
error and alarm codes. Faults prevent the drive from starting until the drive fault is corrected. In
contrast, Alarms are drive conditions which could eventually result in the occurrence of a Fault,
however, Alarms will not prevent the drive from starting.
7.7.1 About The Fault Menu
Access the Fault Menu by pressing the FAULT key until FAULT appears on the OIM directly
above the FAULT key. The following will be displayed.
Fault Menu
" Review Log
Reset Faults
Clear Fault Log and Reset Faults
!!
!!
Fault
Alarm
Interlock OK
Drive Ready
Running
Current Limit
Torque Limit
FAULT KEYPAD MANUAL FORWARD
The following paragraphs will discuss these selections.
7.7.1.1 Review Log
Pressing ENTER with the cursor at Review Log displays the contents of the fault log.
Entries are listed from most recent (higher numbered faults) to the oldest (lower numbered
faults).
Review Log
" 05 CONTROLLER THERMOSTAT TRIP
04 FIELD CURRENT LOSS
03 A-C LINE SYNCHRONIZATION FAULT
02 OIM COMMUNICATIONS TIMEOUT
!!
!!
Fault
Alarm
Interlock OK
Drive Ready
Running
Current Limit
Torque Limit
FAULT KEYPAD MANUAL FORWARD
