APPENDIX B
49’1340 e FlexPak 3000 B-13
DIG OUT 1 CONTACT TYP (P.410)
Only available if the I/O Expansion Kit is installed. Selects whether digital output 1 (terminals 66 and 67
on I/O Expansion board) is normally open or normally closed.
Parameter Range: NORMAL OPEN NORMAL CLOSED
Default Setting: NORMAL OPEN
Parameter Type: Configurable
OIM Menu Path(s): Input/Output - Digital I/O
Refer also to Parameters: DIG OUT 1 SELECT (P.409)
If NORMAL OPEN is selected, digital output 1 is open when the signal is off and closed when it is on.
If NORMAL CLOSED is selected, digital output 1 is closed when the signal is off and open when on.
DANGER
On a power cycle or reset, the contact is held at normally open until the drive software is initialized.
Make sure that this condition does not result in a dangerous situation for your application. Failure to
observe this precaution can result in severe bodily injury or loss of life.
DIG OUT 1 SELECT (P.409)
Only available if the I/O Expansion Kit is installed. NETW IN REG 1, 2, or 3: Bit 0 of NETW IN REG 1
(P.905), 2 (P.906), or 3 (P.907) is used to drive digital output 1 (terminals 66 and 67 on the I/O
Expansion board). Note that the network input registers are updated only when CONTROL SOURCE
(P.000) is set to NETWORK and the network is active.
DANGER
This output is intended for use as an indication. If it is used as a control source, a dangerous condition
can result. Failure to observe this precaution can result in severe bodily injury or loss of life.
Parameter Range: LEVEL DETECT 1 OUTPUT, LEVEL DETECT 2 OUTPUT
IN CURRENT LIMIT, DRIVE READY
NETW COMM STATUS, NETW IN REG 1 (bit 0)
NETW IN REG 2 (bit 0), NETW IN REG 3 (bit 0)
Default Setting: LEVEL DETECT 1 OUTPUT
Parameter Type: Configurable
OIM Menu Path(s): Input/Output - Digital I/O
Refer also to Parameters: LEVEL DETECT 1 OUTPUT (P.648),
LEVEL DETECT 2 OUTPUT (P.649)
NETW COMM STATUS (P.908), NETW IN REG 1 (P.905)
NETW IN REG 2 (P.906),
NETW IN REG 3 (P.907)
DIG OUT 2 CONTACT TYP (P.412)
Only available if the I/O Expansion Kit is installed. Selects whether digital output 2 (terminals 68 and 69
on the I/O Expansion board) is normally open or normally closed.
Parameter Range: NORMAL OPEN, NORMAL CLOSED
Default Setting: NORMAL OPEN
Parameter Type: Configurable
OIM Menu Path(s): Input/Output - Digital I/O
Refer also to Parameters: DIG OUT 2 SELECT (P.411)
If NORMAL OPEN is selected, digital output 2 is open when the signal is off and closed when it is on.
If NORMAL CLOSED is selected, digital output 2 is closed when the signal is off and open when it is on.
DANGER
On a power cycle or reset, the contact is held at normally open until the drive software is initialized.
Make sure that this condition does not result in a dangerous situation for your application. Failure to
observe this precaution can result in severe bodily injury or loss of life.
