FlexPak 3000 Main Menu
~
Input/Output
Meter Outputs
METER OUT 1 SELECT (P.404)
METER OUT 1 ZERO ADJ (P.402)
METER OUT 1 GAIN ADJ (P.400)
METER OUT 2 SELECT (P.405)
METER OUT 2 ZERO ADJ (P.403)
METER OUT 2 GAIN ADJ (P.401)
Analog I/O
I/O EXPANSION KIT (P.797)
ANLG IN 1 SIG TYPE (P.413)
ANLG IN 1 ZERO ADJ (P.414)
ANLG IN 1 GAIN ADJ (P.415)
ANLG IN 1 (P.492)
ANLG IN 2 ZERO ADJ (P.416)
ANLG IN 2 GAIN ADJ (P.417)
ANLG IN 2 (P.493)
ANLG OUT 1 SELECT (P.418)
ANLG OUT 1 SIG TYPE (P.419)
ANLG OUT 1 GAIN ADJ (P.420)
ANLG OUT 2 SELECT (P.421)
ANLG OUT 2 GAIN ADJ (P.422)
Digital I/O
I/O EXPANSION KIT (P.797)
DIG IN 1 (P.495)
DIG IN 2 (P.496)
DIG IN 3 (P.497)
DIG IN 4 (P.498)
DIG IN 5 (P.499)
DIG OUT 1 SELECT (P.409)
DIG OUT 1 CONTACT TYP (P.410)
DIG OUT 2 SELECT (P.411)
DIG OUT 2 CONTACT TYP (P.412)
Frequency I/O
I/O EXPANSION KIT (P.797)
FREQ IN ZERO (P.423)
FREQ IN FULL SCALE (P.424)
FREQ IN (P.491)
FREQ OUT SELECT (P.425)
FREQ OUT ZERO (P.426)
FREQ OUT FULL SCALE (P.427)
Level Detectors
LEVEL DETECT 1 SELECT (P.602)
LEVEL DETECT 1 THRESH (P.603)
LEVEL DETECT 1 DELAY (P.604)
LEVEL DETECT 1 OUTPUT (P.648)
LEVEL DETECT 2 SELECT (P.605)
LEVEL DETECT 2 THRESH (P.606)
LEVEL DETECT 2 DELAY (P.607)
LEVEL DETECT 2 OUTPUT (P.649)
