APPENDIX B
FlexPak 3000 49’1340 e B-50
Sets the threshold speed below which the main contactor will automatically open after a ramp stop or
current limit stop is asserted. This value should be less than or equal to MINIMUM SPEED.
Parameter Range: 0 to MAXIMUM SPEED (RPM or user-defined units)
Default Setting: 0 (RPM or user-defined units)
Parameter Type: Tuneable
OIM Menu Path(s): Drive Reference - Drive Reference Configure
TACH LEAD FLT DELAY (P.228)
The amount of time that parameter TACH LEAD FLT THRESH (P.227) must be exceeded before a
REVERSED TACH LEADS fault (F00014) is generated.
Parameter Range: 0 to 32767 msec
Default Setting: 10 000 msec
Parameter Type: Tuneable
OIM Menu Path(s): Additional Parameters
Refer also to Parameters: TACH LEAD FLT THRESH (P.227)
TACH LEAD FLT THRESH (P.227)
The threshold after which a REVERSED TACH LEADS fault (F00014) is generated.
A REVERSED TACH LEADS fault is generated if the difference between the speed reference
and speed feedback is greater than this value for at least the amount of time set by
TACH LEAD FLT DELAY.
Parameter Range: 0.0 to 250 (% of TOP SPEED)
Default Setting: 200.0
Parameter Type: Tuneable
OIM Menu Path(s): Additional Parameters
Refer also to Parameters: TACH LEAD FLT DELAY (P.228)
TACH LOSS SCR ANGLE (P.608)
The SCR firing angle in degrees at which tach loss is determined when current is present and motor
speed is less than 5% of TOP SPEED.
Parameter Range: 0 to 127 (degrees)
Default Setting: 109
Parameter Type: Tuneable
OIM Menu Path(s): Additional Parameters
The open armature detection algorithm also uses this parameter. An open armature is detected when
the armature current is zero, motor speed feedback is <5% of TOP SPEED, and the SCR firing angle is
equal to TACH LOSS SCR ANGLE.
Use the following steps to adjust this parameter if a tach loss occurs.
Step 1. Check tach lead connections and polarity,
Step 2. Increment TACH LOSS SCR ANGLE by 1.
Step 3. Restart the drive.
Step 4. If tach loss occurs and the angle is less than 127
°
, return to step 2.
WARNING
The incorrect setting of this parameter can cause an overspeed condition.
Set the value of this parameter only as high as necessary to stop incorrect tach loss faults.
Failure to observe this precaution could result in bodily injury.
TOP SPEED (P.011)
