APPENDIX F
49'1340 e FlexPak 3000 F-1
OIM Parameter Menu Tree
This appendix shows the FlexPak 3000 menu structures as they are displayed on the OIM. Parameter
names are in upper case, sub-menu names and menu items which cause an action to occur (such as
resetting faults) are in lower case.
The Fault Menu, Alarm Menu and Diagnostics Menu are accessed by repeated pressing of the OIM
FAULT key. The text "FAULT", "ALARM" or "DIAGS" will appear above the FAULT key.
Fault Menu
Review Log
Reset Faults
Clear Fault Log and Reset Faults
Alarm Menu
Review Log
Reset Alarm Indicator
Clear Alarm Log & Reset Alarms
Diagnostics Menu
Why is the drive not ready?
Why did the drive stop?
To access the Main Menu, press CANCEL until FlexPak 3000 Main Menu is displayed at the top of the
screen. Each menu shown below is expanded on the pages that follow.
FlexPak 3000 Main Menu
Quick Start
Drive Reference
Speed/Voltage Loop (SPD)
Current Minor Loop (CML)
Outer Control Loop (OCL)
Input/Output
Network Communications
Field
Drive Information
Operator Interface
Additional Parameters
If older versions of the OIM are used with newer versions of the regulator board, the menu item
Additional Parameters might also be available.
